AMT 25CS-1 Clear Floor 2 Post Car Lift – Heavy-Duty 4.5-Ton Hydraulic Auto Lift

The AMT 25CS-1 Clear Floor 2 Post Car Lift is a professional-grade lifting solution engineered for automotive workshops, inspection centers, tire service shops, and high-demand garages. With a 4,500 kg (4.5-ton) lifting capacity, this heavy-duty hydraulic lift is designed to handle passenger cars, SUVs, and vans with exceptional stability, safety, and operational efficiency.

Built for continuous professional use, the AMT 25CS-1 combines a clear-floor design, powerful hydraulic performance, and versatile arm configurations—making it an ideal choice for modern auto service environments.

25CS1 Clear Floor 2 Post Car Lift  Heavy-Duty Lifting Capacity

Rated at 4,500 kg, the AMT 25CS-1 delivers reliable lifting power for a wide range of vehicles, from compact sedans to light commercial SUVs and vans. Its robust structure ensures safe and consistent performance under full load, even in busy workshop conditions.

25CS1 Clear Floor 2 Post Car Lift Clear Floor Design for Maximum Accessibility

The clear floor overhead cable design provides unobstructed access beneath the vehicle, making it ideal for:

• Transmission repairs

• Suspension and exhaust work

• Underbody inspections and detailing

This design improves workflow efficiency and allows technicians to move freely without floor obstructions.

25CS1 Clear Floor 2 Post Car Lift Optimized Dimensions for Workshop Flexibility

• Inner Post Width: 2,860 mm – ample space for wide vehicles and technician movement

• Maximum Lift Height: 3,900 mm – suitable for tall vehicles

• Minimum Height: 95 mm – perfect for low-clearance cars

• Tray Adjustment Height: 1,990 mm – supports various wheelbases and service tasks

These dimensions make the AMT 25CS-1 adaptable to diverse workshop layouts and vehicle types.

25CS1 Clear Floor 2 Post Car Lift Adjustable Lifting Arms for Versatile Vehicle Support

The lift features multi-stage adjustable arms for maximum flexibility:

• 3-Stage Arms: 660 mm – 1,050 mm (compact and short-wheelbase vehicles)

• 2-Stage Arms: 910 mm – 1,350 mm (SUVs, vans, and extended chassis vehicles)

This dual arm configuration ensures secure lifting points across a broad range of vehicles.

⚙️ Powerful Motor Options

Choose the power setup that best fits your workshop:

• Three-Phase Motor: 380V AC, 2.2 kW, aluminum alloy housing

• Single-Phase Motor: 220V AC, 2.2 kW, aluminum alloy housing

Both options provide smooth, reliable performance with reduced maintenance requirements.

💧 Reliable Hydraulic System

Operating with ISO 46# anti-wear hydraulic oil, the AMT 25CS-1 delivers efficient, smooth, and long-lasting hydraulic performance—built to withstand heavy daily use in professional garages.

🛡️ Built for Safety & Long-Term Durability

• Heavy-duty powder-coated steel construction for corrosion resistance

• Integrated mechanical safety locks for secure lifting

• Reinforced arm brackets for maximum load stability

Every component is designed to meet professional safety standards and ensure long service life.

Why Choose the AMT 25CS-1 Clear Floor 2 Post Car Lift?

• Designed for professional auto service centers

• 4.5-ton lifting capacity for cars, SUVs, and vans

• Clear floor design for better accessibility and efficiency

• Versatile arm adjustment for multiple vehicle types

• Durable, low-maintenance hydraulic performance

The AMT 25CS-1 Clear Floor 2 Post Car Lift is a smart, long-term investment for workshops seeking strength, flexibility, and dependable performance in a heavy-duty lifting solution.
