<div class="et_pb_module et_pb_wc_title et_pb_wc_title_0_tb_body product-header et_pb_bg_layout_light">
<h4>The Autel MaxiEV ALT100L is an EV battery enclosure integrity and leakage tester for high-voltage battery packs and thermal-management systems. It uses high-sensitivity pressure sensing to measure leakage and airtightness with real-time dual-pressure monitoring.</h4>
The ALT100L can test high-voltage battery enclosures as well as thermodynamic systems such as coolant and A/C circuits. Users can configure pack ID / volume, target pressure, test phase timing and alarm settings, then monitor the complete test process on screen. Autel specifies a 0–30kPa test pressure range, 1Pa sensor resolution and ±5Pa test accuracy. Results and screenshots can be stored or exported for workshop reporting.
</div>
<div class="et_pb_module et_pb_wc_description et_pb_wc_description_0_tb_body et_pb_bg_layout_light et_pb_text_align_left">
<div class="et_pb_module_inner">
<table>
<thead>
<tr><th>Specification</th><th>MaxiEV ALT100L</th></tr>
</thead>
<tbody>
<tr><td>Product Type</td><td>EV Battery Enclosure Leakage / Airtightness Tester</td></tr>
<tr><td>Model</td><td>MaxiEV ALT100L</td></tr>
<tr><td>Applications</td><td>HV Battery Enclosures, Coolant & A/C Systems</td></tr>
<tr><td>Test Pressure Range</td><td>0–30kPa</td></tr>
<tr><td>Sensor Resolution</td><td>1Pa</td></tr>
<tr><td>Test Accuracy</td><td>±5Pa</td></tr>
<tr><td>Dual Pressure Display</td><td>Supported</td></tr>
<tr><td>Custom Presets</td><td>Pack ID / Volume, Pressure, Time, Alarm</td></tr>
<tr><td>Test Monitoring</td><td>On-Screen</td></tr>
<tr><td>Data Storage</td><td>Internal Memory / USB Export</td></tr>
<tr><td>Power</td><td>AC 220V</td></tr>
<tr><td>Air Supply</td><td>0.1–1.0MPa Dry Compressed Air</td></tr>
<tr><td>Software / Support</td><td>2 Years Included – Automax Tools IMEA Package</td></tr>
<tr><td>Warranty</td><td>1 Year Limited Warranty</td></tr>
</tbody>
</table>
<strong>Autel MaxiEV ALT100L Official / Reference Information</strong>
<a href="https://www.autel.com/ev/4192.jhtml" target="_blank" rel="noopener">
View Product Information
</a> <a href="https://automaxtools.me/wp-content/uploads/2024/05/MAXIEV-ALT100L.jpg">
<img class="aligncenter" src="https://automaxtools.me/wp-content/uploads/2024/05/MAXIEV-ALT100L.jpg" alt="Autel MaxiEV ALT100L UAE Automax Tools" width="807" height="807" />
</a> </div>
</div>
<h3><span style="color: #d2322a;">
<strong>1 Year Warranty. 2 Year Free Software Updates.</strong>
</span></h3>
<h4 style="color: red;">IP Restriction (works only in India, Middle East and Africa).</h4> <div class="et_pb_module et_pb_wc_title et_pb_wc_title_0_tb_body product-header et_pb_bg_layout_light">
<h4>The Autel MaxiEV ALT100L is an EV battery enclosure integrity and leakage tester for high-voltage battery packs and thermal-management systems. It uses high-sensitivity pressure sensing to measure leakage and airtightness with real-time dual-pressure monitoring.</h4>
The ALT100L can test high-voltage battery enclosures as well as thermodynamic systems such as coolant and A/C circuits. Users can configure pack ID / volume, target pressure, test phase timing and alarm settings, then monitor the complete test process on screen. Autel specifies a 0–30kPa test pressure range, 1Pa sensor resolution and ±5Pa test accuracy. Results and screenshots can be stored or exported for workshop reporting.
</div>
<div class="et_pb_module et_pb_wc_description et_pb_wc_description_0_tb_body et_pb_bg_layout_light et_pb_text_align_left">
<div class="et_pb_module_inner">
<table>
<thead>
<tr><th>Specification</th><th>MaxiEV ALT100L</th></tr>
</thead>
<tbody>
<tr><td>Product Type</td><td>EV Battery Enclosure Leakage / Airtightness Tester</td></tr>
<tr><td>Model</td><td>MaxiEV ALT100L</td></tr>
<tr><td>Applications</td><td>HV Battery Enclosures, Coolant & A/C Systems</td></tr>
<tr><td>Test Pressure Range</td><td>0–30kPa</td></tr>
<tr><td>Sensor Resolution</td><td>1Pa</td></tr>
<tr><td>Test Accuracy</td><td>±5Pa</td></tr>
<tr><td>Dual Pressure Display</td><td>Supported</td></tr>
<tr><td>Custom Presets</td><td>Pack ID / Volume, Pressure, Time, Alarm</td></tr>
<tr><td>Test Monitoring</td><td>On-Screen</td></tr>
<tr><td>Data Storage</td><td>Internal Memory / USB Export</td></tr>
<tr><td>Power</td><td>AC 220V</td></tr>
<tr><td>Air Supply</td><td>0.1–1.0MPa Dry Compressed Air</td></tr>
<tr><td>Software / Support</td><td>2 Years Included – Automax Tools IMEA Package</td></tr>
<tr><td>Warranty</td><td>1 Year Limited Warranty</td></tr>
</tbody>
</table>
<strong>Autel MaxiEV ALT100L Official / Reference Information</strong>
<a href="https://www.autel.com/ev/4192.jhtml" target="_blank" rel="noopener">
View Product Information
</a> <a href="https://automaxtools.me/wp-content/uploads/2024/05/MAXIEV-ALT100L.jpg">
<img class="aligncenter" src="https://automaxtools.me/wp-content/uploads/2024/05/MAXIEV-ALT100L.jpg" alt="Autel MaxiEV ALT100L UAE Automax Tools" width="807" height="807" />
</a> </div>
</div>
<h3><span style="color: #d2322a;">
<strong>1 Year Warranty. 2 Year Free Software Updates.</strong>
</span></h3>
<h4 style="color: red;">IP Restriction (works only in India, Middle East and Africa).</h4>

Autel MaxiEV ALT100L EV Battery Leakage Tester | Enclosure Airtightness | Dual Pressure Display | ±5Pa Accuracy | 2-Year Updates

Name: Best Autel MaxiEV ALT100L | EV Battery Leakage & Airtightness Tester 2025
SKU: AMT0134
Price: 12430.00 AED
Availability: InStock
Rating: 5.00 (10 reviews)

Categories: EV Protection Gears, Autel, Autel EV, Battery Chargers & Booster, EV Services, Product Category SKU: AMT0134

AED 12,430.00

Rated 5.00 out of 5

10 reviews

The Autel MaxiEV ALT100L is an EV battery enclosure integrity and leakage tester for high-voltage battery packs and thermal-management systems. It uses high-sensitivity pressure sensing to measure leakage and airtightness with real-time dual-pressure monitoring.

The ALT100L can test high-voltage battery enclosures as well as thermodynamic systems such as coolant and A/C circuits. Users can configure pack ID / volume, target pressure, test phase timing and alarm settings, then monitor the complete test process on screen.

Autel specifies a 0–30kPa test pressure range, 1Pa sensor resolution and ±5Pa test accuracy. Results and screenshots can be stored or exported for workshop reporting.

Specification	MaxiEV ALT100L
Product Type	EV Battery Enclosure Leakage / Airtightness Tester
Model	MaxiEV ALT100L
Applications	HV Battery Enclosures, Coolant & A/C Systems
Test Pressure Range	0–30kPa
Sensor Resolution	1Pa
Test Accuracy	±5Pa
Dual Pressure Display	Supported
Custom Presets	Pack ID / Volume, Pressure, Time, Alarm
Test Monitoring	On-Screen
Data Storage	Internal Memory / USB Export
Power	AC 220V
Air Supply	0.1–1.0MPa Dry Compressed Air
Software / Support	2 Years Included – Automax Tools IMEA Package
Warranty	1 Year Limited Warranty

Autel MaxiEV ALT100L Official / Reference Information

View Product Information

1 Year Warranty. 2 Year Free Software Updates.

IP Restriction (works only in India, Middle East and Africa).

Order on WhatsApp

Only 1 left in stock

Description
Customer Reviews (10)

Autel MaxiEV ALT100L – Battery Enclosure Integrity & Leakage Testing

The Autel MaxiEV ALT100L provides controlled low-pressure leakage testing for EV high-voltage battery enclosures and thermal-management systems.
It is designed to help workshops confirm sealing integrity after battery, coolant or enclosure repair.

Battery Enclosure Airtightness Testing

The ALT100L applies controlled pressure and measures pressure change to evaluate enclosure leakage.

Dual Real-Time Pressure Display

The instrument displays both current pressure and leakage fluctuation in real time, improving visibility during the test process.

High-Sensitivity Measurement

Official specifications include:

0–30kPa test pressure range
1Pa sensor resolution
±5Pa test accuracy
0.1–1.0MPa dry compressed-air supply

Customizable Test Presets

Technicians can configure pack ID / volume, target pressure, test-phase duration and alarm settings for repeatable workshop procedures.

Report & USB Data Support

Test parameters and result screenshots can be stored and exported by USB for documentation.

Warranty, Software Package & Regional Version

The Automax Tools IMEA package for Autel MaxiEV ALT100L includes 2 years of software updates/support where applicable and a 1-year limited warranty.
Regional restriction: this listing is intended for use in India, the Middle East and Africa.

Ideal for Professional Use

The Autel MaxiEV ALT100L is well suited for:

EV battery repair
Collision repair centers
High-voltage workshops
Battery remanufacturing
EV inspection facilities

Why Choose the Autel MaxiEV ALT100L?

The ALT100L provides repeatable, documented enclosure integrity testing for EV battery and thermal systems after service or repair.
Coverage, functions, programming, charging performance and supported procedures can vary by vehicle, installation, software version, connector standard and region.
