Autel MaxiCharger DC V2X 12kW Bi-Directional EV Charger | V2H / V2G | CCS1 / CHAdeMO | HEMS & Backup Power
Autel MaxiCharger DC V2X is a smart bi-directional DC charger designed to let a compatible EV
both receive power and supply stored battery energy back to a home or supported energy system. It supports up to
12kW bi-directional power and is designed for V2H / V2G energy-management applications.
Key Features
- Up to 12kW Bi-Directional Power: supports EV charging and controlled discharge from a compatible vehicle battery.
- Vehicle-to-Home / Vehicle-to-Grid: designed to support backup-power and energy-management applications where vehicle and grid compatibility allow.
- Intelligent Backup Switching: can work with the appropriate system architecture to use EV battery energy during a power outage.
- HEMS Ready: compatible with Home Energy Management System integration for intelligent power control.
- Solar & Energy Storage Integration: designed for smart micro-grid applications combining EV, solar and storage resources.
- CCS1 / CHAdeMO Configurations: available in supported connector configurations depending on market and project specification.
Quick Specifications
| Output Power | 7 / 12kW configuration; up to 12kW bi-directional power |
|---|---|
| DC Voltage | CCS1: 150–950V DC; CHAdeMO: 150–500V DC |
| Output Current | 40A @ 300V |
| Peak Efficiency | ≥97% |
| AC Input | 208 / 240V AC, 60Hz |
| Enclosure | NEMA 4X |
1 Year Warranty.
Autel MaxiCharger DC V2X – 12kW Bi-Directional EV Charger
The Autel MaxiCharger DC V2X is designed around vehicle-to-everything technology, allowing a compatible
electric vehicle battery to function as more than a transportation energy source. In addition to charging the vehicle,
the system is designed to support controlled discharge of stored EV energy for home backup, peak-demand management
and supported grid-interactive applications.
12kW Bi-Directional Power Conversion
The MaxiCharger DC V2X supports up to 12kW bi-directional power. Depending on the selected configuration
and compatible vehicle, energy can flow from the electrical system to the EV for charging or from the EV battery back
toward a supported home or energy-management system.
Vehicle-to-Home Backup Power
With the required system components and compatible EV, V2X can support backup-power operation. Autel describes an
intelligent switching architecture that can isolate the home from the grid during a blackout and use energy stored in
the EV battery to supply supported loads.
Vehicle-to-Grid & Peak Energy Management
The platform is designed to support advanced energy-management use cases including scheduled discharge during
high-cost periods and, where local regulations, utility programs and vehicle compatibility permit, controlled export
of energy back toward the grid.
HEMS, Solar & Energy Storage Integration
- Compatible with Home Energy Management System integration.
- Designed to work as part of a smart micro-grid architecture.
- Can be integrated with supported solar and stationary energy-storage systems.
- Helps coordinate vehicle charging and discharge around site energy demand.
Connector & Charging Configuration
DC V2X configurations support CCS1 or CHAdeMO depending on the selected version. The original
specification supports 7kW / 12kW configurations, with the platform marketed around up to 12kW bi-directional operation.
Technical Specifications
| Charging Mode / Connector | CCS1 or CHAdeMO |
|---|---|
| Output Power | 7 / 12kW configuration; up to 12kW bi-directional power |
| CCS1 Output Voltage | 150–950V DC |
| CHAdeMO Output Voltage | 150–500V DC |
| Output Current | 40A @ 300V |
| Number of Outputs | 1 × CCS1 or 1 × CHAdeMO |
| Peak Efficiency | ≥97% |
| AC Input Voltage | 208 / 240V AC |
| Input Frequency | 60Hz |
| Power Factor | ≥0.99 |
| Enclosure Rating | NEMA 4X |
| Operating Temperature | -25°C to +50°C |
| Dimensions | 386 × 711 × 170 mm (W × H × D) |
Important Compatibility Notice
Bi-directional charging requires a compatible EV, appropriate connector / communication support, correct electrical
installation and any required transfer, energy-management or grid-interface equipment. V2H and V2G functionality can
also depend on vehicle manufacturer support, utility rules, local regulations and project configuration. Confirm the
intended application before ordering.
1 Year Warranty.
Note: Connector type and final system configuration vary by market and project requirement.
Contact Automax Tools for compatibility confirmation before installation.
