Autel G-Box3

د.إ 545.00

(0 reviews)

Autel G-BOX 3 FASTER, MORE SECURE

COMPATIBLE WITH THE MAXIIM IM608, IM608PRO, IM608PRO II AND IM508

Supports on-vehicle and on-bench Fast Mode in an All Keys Lost scenario for Mercedes-Benz vehicles using the DAS3 EIS/EZS.

Bosch engine ECU read and write on BMW F-chassis and Volkswagen MQB vehicles.

Updated version of Autel G-BOX 2



Order on WhatsApp

Description

Autel G-BOX3 Accessory Tool for Mercedes Benz All Key Lost

The Autel G-Box3 adapter, compatible with the MaxiM IM608Pro, IM608, and IM508 (with an additional purchase of XP400), offers faster and more secure reading and writing of Bosch EDC17, MEx17, MD1, and MG1 CUs and supports on-vehicle and on-bench Fast Mode in Mercedes-Benz All Keys Lost scenario.

What’s New in Autel G-box3?

* FASTER, MORE SECURE
* Supports on-vehicle and on-bench Fast Mode in an All Keys Lost scenario for Mercedes-Benz vehicles using the DA S3 EIS/EZS.
* Bosch engine ECU read and write on BMW F-chassis, PSA group and Volkswagen MQB vehicles

G-BOX 3 FEATURES

* Faster password calculation for Mercedes-Benz All Key Lost scenario
* 8x faster password calculation for Mercedes-Benz W172, W204 and W207 ElS types
* 4X faster password calculation for Mercedes-Benz W209 and W211 El S types
* BMW ME/DDE ISN reading for 20 types of ECUs, including EDC17, MEVD17, MSV90, and MSD87
* Volkswagen CM IMMO data reading and data synchronization for 18 types, including MQB EDC17 and MED17 ECUs
* Bosch engine ECU read and write on Volkswagen, BMW, and PSA group vehicles.

Functions:

1) COMPATIBLE WITH THE MAXIM IM608, IM6O8PRO AND IM508 (WITH THE PURCHASE OF THE XP400).
2) Supports on-vehicle and on-bench Fast Mode in an All Keys Lost scenario for Mercedes-Benz vehicles using the DAS3 EIS/EZS
3) Bosch engine ECU read and write on BMW F-chassis and Volkswagen MQB vehicles

Autel gbox-3

Features

  •  Faster password calculation for Mercedes-Benz All Key Lost scenario
  •  8x faster password calculation for Mercedes-Benz W172, W204 and W207 EIS types
  • 4X faster password calculation for Mercedes-Benz W209 and W211 EIS types
  • BMW DME/DDE ISN reading for 20 types of ECUs, including EDC17, MEVD17, MSV90, and MSD87
  • Volkswagen ECM IMMO data reading and data synchronization for 18 types, including MQB EDC17 and MED17 ECUs
  • Bosch engine ECU read and write on Volkswagen, BMW, and PSA group vehicles.

Product Display

autel g box 2

  1. DC Port – Provides +12V DC power supply.
  2. CAN-H Port – Universal CAN bus interface, connects with OBDII Pin6
  3. K1 Port – Universal K-Line interface, connects with OBDII Pin1
  4. Status Indicator – Indicates the current operating status
  5. Relay Ports – Connect with dedicated relay cables
  6. +12V Power Port – Universal power input/ output port
  7. OBDII Connector – Connects to the vehicle’s OBDII directly or via a dedicated extension cable
  8. OBDII Female Connector – Connects to the main cable of Autel diagnostic tablet
  9. CAN-L Port – Universal CAN Bus interface, connects with OBDII Pin14
  10. K7 Port – Universal K-Line interface, connects with OBDII Pin7
  11. GND Port – Universal power input/ output port
  12. DB15 Port – Used with dedicated DB15 cable for reading and writing multiple types of ECUs

Troubles and Troubleshooting:

When all the keys of the Mercedes-Benz vehicle are lost, you can operate through the OBD.

Notice:

This method is suitable for Mercedes-Benz W204, W207, W216, and W164 EISs after the year 2009.

Connection Method

  1. Connect the G-Box3 to vehicle’ s OBDII
  2. Remove the fuse of vehicle EIS, Connect the Relay ports to the fuse using the supplied fuse cable
  3. When the vehicle has an ELV, connect the K7 port and ELV plug using the supplied K-line cable
  4. Connect the G-Box3 to the Autel Diagnostic Tablet (MaxiIM IM608, IM508)

How to do on Bench When All Keys of Mercedes-Benz Vehicle are Lost?

Notice:

This Method is suitable for all Mercedes-Benz EISs that are already supported by Autel Diagnostic Tablet

How to Connection Autel G-Box3 ?

  1. Plug the G-Box3 to the Mercedes-Benz EIS using the packed DB15 Cable
  2. Plug to the DC port of G-Box3 using a power adapter (DV 12V)
  3. Plug the G-Box3 to the Autel Diagnostic Tablet (MaxiIM IM608, IM508)

Gbox 2 vs Gbox3

Gbox2 makes Mercedes all keys lost faster, Gbox3 makes it 4x/8x faster
Gbox3 offers faster and more secure reading and writing of Bosch EDC17, MEx17, MD1, and MG1 ECUs and supports on vehicle.


Gbox2Gbox3
• Faster password calculation for Benz All Key Lost
• 8X times faster password calculation for W172, W204, W207
• 4X times faster password calculation for W209, W211
• No more repeated insertions and removals of IR simulator for 10 types of EIS
• Passport reading for 9 type EIS when all keys lost on vehicle
• BMW DME/DDE ISN reading for 20 types (EDC17, MEVD17, MSV90, MSD87, etc)
• VAG ECM IMMO data reading & data synchronization for 18 types (MQB EDC17, MED17, etc)
• XP400 Pro may be required for certain functions
• Faster password calculation for Benz All Key Lost
• 8X times faster password calculation for W172, W204, W207
• 4X times faster password calculation for W209, W211
• No more repeated insertions and removals of IR simulator for 10 types of EIS
• Passport reading for 9 type EIS when all keys lost on vehicle
• BMW DME/DDE ISN reading for 20 types (EDC17, MEVD17, MSV90, MSD87, etc)
• VAG ECM IMMO data reading & data synchronization for 18 types (MQB EDC17, MED17, etc)
• Engine ECU reading/writing for BOSCH MD1/MG1(VAG,BMW,PSA,OPEL,etc)
• XP400 Pro may be required for certain functions
